This kind of products is suitable for attracting and lifting steel band roll. The products are divided into vertical lifting & transporting type, horizontal lifting & transporting type and general type(which can lift & transport both vertically and horizontally).High-temperature special electromagnet is specially used for new annealed technological process of roll plate. It can work under high temperature of 100?-600?,and lift & transport band roll vertically or horizontally. Vertical lifting & transporting type-the electromagnet attracts and holds the end face of band roll. It is suitable for lifting and transporting packed or unpacked band roll. Horizontal lifting & transporting type-the electromagnet attracts and holds the side face of band roll, the band roll must be packed and bunched.

Main technical data:
Model:MW16-190190L/G
Current (A):70
Power (kw):15.4
Mass (kg):4400
Steel band roll (weight)(T):16
Steel band roll (outside diameter)(mm):1700
Steel band roll (width) (mm):1220
